2.3(090) SERIES II FEMALE 2 WAY SEALED CONNECTOR

  1. https://www.t-g-s.de/images/housings/20-2-36.jpg
Item 1 of 1
Hersteller:APTIV
Hersteller-Nr.:15316307
Beschreibung:2.3(090) SERIES II FEMALE 2 WAY SEALED CONNECTOR
Poligkeit:2
Gedichtet:nein
Farbe:LIGHT GREY
Gehäuse­sicherung/Sekundär­verriegelung:ja
TGS Gehäuse-ID: 20-2-36
Serie: 2.3 (090) SERIES II
Entriegelungswerkzeuge: Bestückte Kontakte: Flachsteckermass:

F595

2 × Sumitomo TS/DL/SL series 2.3mm(090) female terminal unsealed2.30 x 0.64

F425

1 × secondary lock
Teile-NummerHerstellerBeschreibungKabelquadratOberfläche
7116-4026YAZAKI2.3II(090II) FEMALE SEALED TERMINAL0.85-1.25VERZINNT
7158-3006-90YAZAKI2.3II 6 MM PITCH RUBBER STOPPER0.30-0.85
7116-4029-08YAZAKI2.3II(090II) FEMALE SEALED TERMINAL0.85-1.25VERGOLDET
7116-4027YAZAKI2.3II(090II) FEMALE SEALED TERMINAL2.00VERZINNT
7116-4025YAZAKI2.3II(090II) FEMALE SEALED TERMINAL0.30-0.50VERZINNT
7116-4028-08YAZAKI2.3II(090II) FEMALE SEALED TERMINAL0.30-0.50VERGOLDET
7225-0714-02YAZAKIFEMALE TERMINAL /SOCKET 5.0MM0.75-1.00VERZINNT
8100-1344SUMITOMOTS 2.3(090) SERIES FEMALE SEALED TERMINAL0.30-0.50VERGOLDET
8240-4932SUMITOMOTS/DL SERIES 4.8(187) FEMALE UNSEALED TERMINAL2.00-3.00VERZINNT
8240-4892SUMITOMOTS/DL/SL 2.3(090) SERIES FEMALE UNSEALED TERMINAL0.50-1.25VERZINNT
90980-09152TOYOTADUMMY PLUG TS/SL/MT/HM 2.3(090) SERIES
82999-12030TOYOTAWIRE SEAL1.25
82999-12020TOYOTAWIRE SEAL1.25
82998-24410TOYOTATS/DL/SL 2.3(090) SERIES FEMALE UNSEALED TERMINAL WITH 500MM WIREVERGOLDET
82998-24400TOYOTATS/DL/SL 2.3(090) SERIES FEMALE UNSEALED TERMINAL WITH 500MM WIREVERGOLDET
82998-12800TOYOTA2.3(090) II FEMALE SEALED TERMINAL WITH 500MM WIREVERGOLDET
82998-12590TOYOTA2.3(090) II FEMALE SEALED TERMINAL WITH 500MM WIREVERGOLDET
82998-12440TOYOTA2.3(090) FEMALE SEALED TERMINAL WITH 160MM WIRE0.20-0.60VERZINNT
82998-12460TOYOTA2.3(090) II FEMALE SEALED TERMINAL WITH 160MM WIRE0.20-0.60VERGOLDET
30656672VOLVOTS/DL/SL 2.3(090) SERIES FEMALE UNSEALED TERMINAL1.00VERZINNT
9162046VOLVO2.3II(090II) FEMALE SEALED TERMINAL0.30-0.50VERGOLDET
30656674VOLVOTS/DL/SL 2.3(090) SERIES FEMALE UNSEALED TERMINAL1.50-2.50VERZINNT
