Item 1 of 1
| Hersteller: | TE CONNECTIVITY |
|---|---|
| Hersteller-Nr.: | 2236046-2 |
| Beschreibung: | MCON 1.2/MCP 2.8/4.8 MALE 32 WAY SEALED CONNECTOR |
| Poligkeit: | 32 |
| Gedichtet: | nein |
| Farbe: | GREY |
| Gehäusesicherung/Sekundärverriegelung: | ja |
| TGS Gehäuse-ID: | 55-1-33 |
|---|---|
| Gegengehäuse: | 2236047-1 |
| Serie: | MCON 1.2 |
| Entriegelungswerkzeuge: | Bestückte Kontakte: | Flachsteckermass: |
F1003 | 26 × Tyco/AMP MCON 1.2 male terminal | 1.20 x 0.64 |
G215 | 2 × Tyco/AMP Timer male terminal 5.8 symmetric | 5.80 x 0.80 |
G215 | 4 × Tyco/AMP Timer male terminal 2.8 symmetric | 2.80 x 0.80 |
F425 | 1 × secondary lock |
| Hersteller-Nr. | Beschreibung |
|---|---|
| 2236047-1 | MCON 1.2/MCP 2.8/4.8 FEMALE 32 WAY UNSEALED CONNECTOR |
| Teile-Nummer | Hersteller | Beschreibung | Kabelquadrat | Oberfläche |
|---|---|---|---|---|
| 1/14258/55 | FIAT | 0.64 CONNECTOR SYSTEM FEMALE SEALED/UNSEALED TERMINAL | 0.50-0.80 | VERGOLDET |
| 1/14259/55 | FIAT | |||
| 638551-1 | TE CONNECTIVITY | 0.64 CONNECTOR SYSTEM FEMALE SEALED/UNSEALED TERMINAL | 0.50-0.80 | VERZINNT |
| 1/14649/54 | MAN | MCON 1.2 MALE TERMINAL | 1.00-1.50 | VERZINNT |
| 1/14657/54 | FIAT | TIMER MALE TERMINAL 5.8 SYMMETRIC | 1.00-2.50 | VERZINNT |
| 1/14649/55 | FIAT | MCON 1.2 MALE TERMINAL | 1.00-1.50 | VERGOLDET |
| 1/14648/55 | FIAT | MCON 1.2 MALE TERMINAL | 0.50-0.75 | VERGOLDET |
| 1/14648/54 | FIAT | MCON 1.2 MALE TERMINAL | 0.50-0.75 | VERZINNT |
| 1/14653/54 | FIAT | TIMER MALE TERMINAL 2.8 SYMMETRIC | 1.50-2.50 | VERZINNT |
| 1418762-1 | TE CONNECTIVITY | MCON 1.2 MALE TERMINAL | 1.00-1.50 | VERZINNT |
| 1-963735-1 | TE CONNECTIVITY | TIMER MALE TERMINAL 5.8 SYMMETRIC | 1.00-2.50 | VERZINNT |
| 1-963736-1 | TE CONNECTIVITY | TIMER MALE TERMINAL 5.8 SYMMETRIC | 2.50-4.00 | VERZINNT |
| 1-963860-1 | TE CONNECTIVITY | TIMER MALE TERMINAL 2.8 SYMMETRIC | 0.20-0.50 | VERZINNT |
| 1-965984-1 | TE CONNECTIVITY | TIMER MALE TERMINAL 5.8 SYMMETRIC | 0.20-0.50 | VERZINNT |
| 1-968050-1 | TE CONNECTIVITY | TIMER MALE TERMINAL 5.8 SYMMETRIC | 4.00-6.00 | VERZINNT |
| 1-968946-1 | TE CONNECTIVITY | TIMER MALE TERMINAL 2.8 SYMMETRIC | 4.00 | VERZINNT |
| 5-1418760-1 | TE CONNECTIVITY | MCON 1.2 MALE TERMINAL | 0.50-0.75 | VERZINNT |
| 5-1418758-1 | TE CONNECTIVITY | MCON 1.2 MALE TERMINAL | 0.25-0.35 | VERZINNT |
| 1-962841-1 | TE CONNECTIVITY | TIMER MALE TERMINAL 2.8 SYMMETRIC | 0.50-1.00 | VERZINNT |
| 1-962842-1 | TE CONNECTIVITY | TIMER MALE TERMINAL 2.8 SYMMETRIC | 1.00-2.50 | VERZINNT |
| 1/14659/54 | FIAT | TIMER MALE TERMINAL 5.8 SYMMETRIC | 4.00-6.00 | VERZINNT |
| 1/14652/54 | MAN | TIMER MALE TERMINAL 2.8 SYMMETRIC | 0.50-1.00 | VERZINNT |
| 1/14647/54 | FIAT | MCON 1.2 MALE TERMINAL | 0.25-0.35 | VERZINNT |
| 1-963734-1 | TE CONNECTIVITY | TIMER MALE TERMINAL 5.8 SYMMETRIC | 0.50-1.00 | VERZINNT |
| 5-963860-1 | TE CONNECTIVITY | TIMER MALE TERMINAL 2.8 SYMMETRIC | 0.20-0.50 | VERZINNT |
| 2236048-1 | TE CONNECTIVITY | KIT SEC.LOCK FOR 32 WAYS CON | ||
| 5-1418760-2 | TE CONNECTIVITY | MCON 1.2 MALE TERMINAL | 0.50-0.75 | VERGOLDET |
| 1418762-2 | TE CONNECTIVITY | MCON 1.2 MALE TERMINAL | 1.00-1.50 | VERGOLDET |
| 7114-2212-02 | YAZAKI | TIMER MALE TERMINAL 5.8 SYMMETRIC | 1.50-2.50 | VERZINNT |
| 7114-3766-02 | YAZAKI | TIMER MALE TERMINAL 2.8 SYMMETRIC | 4.00 | VERZINNT |
| 7114-3343-02 | YAZAKI | TIMER MALE TERMINAL 2.8 SYMMETRIC | 1.50-2.50 | VERZINNT |
| 7295-0086-02 | YAZAKI | MCON 1.2 MALE TERMINAL | 0.25-0.35 | VERZINNT |
| 8V5T-14421-AJA | FORD | TIMER MALE TERMINAL 2.8 SYMMETRIC | 0.50-1.00 | VERZINNT |
| EHCT-14421-AMA | FORD | MCON 1.2 MALE TERMINAL | 1.00-1.50 | VERZINNT |
| 320265242 | LEAR | |||
| 320265234 | LEAR | 0.64 CONNECTOR SYSTEM FEMALE SEALED/UNSEALED TERMINAL | 0.50-0.80 | VERGOLDET |
| 32025Y1L9 | LEAR | TIMER MALE TERMINAL 2.8 SYMMETRIC | 4.00 | VERZINNT |
| 32025Y2WA | TE CONNECTIVITY | TIMER MALE TERMINAL 5.8 SYMMETRIC | 4.00-6.00 | VERZINNT |
| 320261399 | LEAR | TIMER MALE TERMINAL 2.8 SYMMETRIC | 1.50-2.50 | VERZINNT |
| E08046000 | LEAR | MCON 1.2 MALE TERMINAL | 0.25-0.35 | VERZINNT |
| E08046100 | LEAR | MCON 1.2 MALE TERMINAL | 0.50-0.75 | VERZINNT |
| 414363460 | LEONI | MCON 1.2 MALE TERMINAL | 1.00-1.50 | VERZINNT |
| P00005123 | TE CONNECTIVITY | TIMER MALE TERMINAL 2.8 SYMMETRIC | 0.50-1.00 | VERZINNT |
| P00072420 | LEONI | TIMER MALE TERMINAL 5.8 SYMMETRIC | 1.00-2.50 | VERZINNT |
| P00111267 | LEONI | MCON 1.2 MALE TERMINAL | 0.25-0.35 | VERZINNT |
| P00519763 | LEONI | MCON 1.2 MALE TERMINAL | 0.25-0.35 | VERZINNT |
| TPA P00165351 | LEONI | KIT SEC.LOCK FOR 32 WAYS CON |
| 1-1579007-3 | TYCO EXTRACTION TOOL AMP MCP 4.8/6.3 CONTACT |
|---|---|
| 5-1579007-3 | TYCO EXTRACTION TOOL FOR MCON 1.2 LL CONTACT |
| 5-1579008-2 | TYCO EXTRACTION TOOL AMP MCON 2.8 CONTACT |
