Item 1 of 1
| Hersteller: | TOKAI RIKA CO. LTD. |
|---|---|
| Hersteller-Nr.: | 4F1040-000 |
| Beschreibung: | 2.3(090)/4.8(187) FEMALE 10 WAY UNSEALED CONNECTOR |
| Poligkeit: | 10 |
| Gedichtet: | ja |
| Farbe: | NATURAL |
| Gehäusesicherung/Sekundärverriegelung: | ja |
| TGS Gehäuse-ID: | 21-1-30 |
|---|---|
| Steckercode: | Hybrid |
| Anleitungsnummer: | female |
| Anwendungs- / Produktspezifikation: | 2.30 / 4.80 |
| Entriegelungswerkzeuge: | Bestückte Kontakte: | Flachsteckermass: |
F450 | 4 × Sumitomo TS/HX/DL 4.8mm(187) female terminal | 4.80 x 0.80 |
F450 | 6 × Sumitomo TS/DL/SL series 2.3mm(090) female terminal unsealed | 2.30 x 0.64 |
F425 | 1 × secondary lock |
| Teile-Nummer | Hersteller | Beschreibung | Kabelquadrat | Oberfläche |
|---|---|---|---|---|
| 8240-4932 | SUMITOMO | TS/DL SERIES 4.8(187) FEMALE UNSEALED TERMINAL | 2.00-3.00 | VERZINNT |
| 1800-3077 | SUMITOMO | 025 FEMALE TERMINAL | ||
| 8240-4882 | SUMITOMO | TS/DL/SL 2.3(090) SERIES FEMALE UNSEALED TERMINAL | 0.30-0.50 | VERZINNT |
| 8240-4892 | SUMITOMO | TS/DL/SL 2.3(090) SERIES FEMALE UNSEALED TERMINAL | 0.50-1.25 | VERZINNT |
| 8240-4922 | SUMITOMO | TS/DL SERIES 4.8(187) FEMALE UNSEALED TERMINAL | 0.50-1.25 | VERZINNT |
| 82998-12360 | TOYOTA | 2.3(090) II FEMALE UNSEALED TERMINAL | VERGOLDET | |
| 90980-09325 | TOYOTA | 4.8 SEALED CONNECTOR BLIND PLUG | ||
| 82999-12030 | TOYOTA | WIRE SEAL | 1.25 | |
| 82999-12020 | TOYOTA | WIRE SEAL | 1.25 | |
| 82998-74050 | TOYOTA | 2.3(090) II FEMALE SEALED TERMINAL WITH WIRE | ||
| 82998-12380 | TOYOTA | TS/DL 4.8(187) SERIES FEMALE UNSEALED TERMINAL WITH 160MM WIRE | 0.30-0.50 | VERZINNT |
| 82998-12340 | TOYOTA | 2.3(090) II FEMALE UNSEALED TERMINAL WITH 160MM WIRE | VERZINNT | |
| 82998-24380 | TOYOTA | 2.3(090) II FEMALE SEALED TERMINAL WITH 160MM WIRE | VERGOLDET |
