NMWP FEMALE 2 WAY SEALED TURN SIGNAL LAMP CONNECTOR

  1. https://www.t-g-s.de/images/housings/89-1-12.jpg
Item 1 of 1
Hersteller:FURUKAWA/KUM
Hersteller-Nr.:PB625-02027
Beschreibung:NMWP FEMALE 2 WAY SEALED TURN SIGNAL LAMP CONNECTOR
Poligkeit:2
Gedichtet:nein
Farbe:BLACK
Gehäuse­sicherung/Sekundär­verriegelung:ja
TGS Gehäuse-ID: 89-1-12
Serie: NMWP SERIES (090 CONNECTOR)
Entriegelungswerkzeuge: Bestückte Kontakte: Flachsteckermass:

F480

2 × Furukawa CS/NS/LC/HC II female 2.3mm(090)terminal2.30 x 0.64

F425

1 × secondary lock
Teile-NummerHerstellerBeschreibungKabelquadratOberfläche
MT095-63080FURUKAWA/KUMNMWP II SERIES 2.3(090) FEMALE SEALED TERMINAL0.30-0.50VERZINNT
RS220-03100FURUKAWA/KUMNDWP SERIES 2.3(090) WIRE SEAL
TP015-00410FURUKAWA/KUMNDWP SERIES 2.3(090) FEMALE SEALED TERMINAL0.22VERGOLDET
TP015-00400FURUKAWA/KUMNDWP SERIES 2.3(090) FEMALE SEALED TERMINAL0.22VERZINNT
TN025-00210FURUKAWA/KUMNDWP SERIES 2.3(090) FEMALE SEALED TERMINAL0.61-0.85VERGOLDET
TN025-00200FURUKAWA/KUMNDWP SERIES 2.3(090) FEMALE SEALED TERMINAL0.61-0.85VERZINNT
RS220-04100FURUKAWA/KUMNDWP SERIES 2.3(090) WIRE SEAL
RS220-02100FURUKAWA/KUMNDWP SERIES 2.3(090) WIRE SEAL
RS220-01100FURUKAWA/KUMNDWP SERIES 2.3(090) WIRE SEAL
PZ001-15022FURUKAWA/KUMNDWP SERIES 2.3(090) DUMMY PLUG
MT095-63260FURUKAWA/KUMNMWP II SERIES 2.3(090) FEMALE SEALED TERMINAL1.25-2.00VERGOLDET
MT095-63060FURUKAWA/KUMNMWP II SERIES 2.3(090) FEMALE SEALED TERMINAL0.30-0.50VERGOLDET
MT095-63280FURUKAWA/KUMNMWP II SERIES 2.3(090) FEMALE SEALED TERMINAL1.25-2.00VERZINNT
